Export trace data to BigQuery

Load LangSmith trace data into BigQuery using bulk export to GCS.

Plan restrictions apply

Bulk export is only available on LangSmith Plus or Enterprise tiers.

LangSmith can export trace data to a Google Cloud Storage (GCS) bucket in Parquet format. From there, you can load it into BigQuery as an external table (queried in place from GCS) or as a native table (copied into BigQuery storage).

This guide covers:

• Setting up a GCS bucket and HMAC credentials for LangSmith.
• Creating a bulk export destination and export job.
• Loading the exported data into BigQuery.

For full details on bulk export configuration options, refer to Bulk export trace data and Manage bulk export destinations.

Prerequisites

• Data in your LangSmith Tracing project.
• gcloud CLI installed. (You can also use the Google Cloud console for setup.)

1. Create a GCS bucket

Create a dedicated GCS bucket for LangSmith exports. Using a dedicated bucket makes it easier to grant scoped permissions without affecting other data:

gcloud storage buckets create gs://YOUR_BUCKET_NAME \
  --location=US \
  --uniform-bucket-level-access

Choose a region close to your BigQuery dataset to minimize latency and avoid cross-region egress charges.

2. Create a service account and grant access

Create a GCP service account that LangSmith will use to write data to GCS:

gcloud iam service-accounts create langsmith-bulk-export \
  --display-name="LangSmith Bulk Export"

Grant the service account write access to your bucket. The minimum required permission is storage.objects.create. Granting storage.objects.delete is optional, but recommended. LangSmith uses it to clean up a temporary test file created during destination validation. If this permission is absent, a tmp/ folder may remain in your bucket.

The “Storage Object Admin” predefined role covers all required and recommended permissions:

gcloud storage buckets add-iam-policy-binding gs://YOUR_BUCKET_NAME \
  --member="serviceAccount:langsmith-bulk-export@YOUR_PROJECT.iam.gserviceaccount.com" \
  --role="roles/storage.objectAdmin"

To use a minimal custom role instead, grant only:

• storage.objects.create (required)
• storage.objects.delete (optional, for test file cleanup)
• storage.objects.get (optional but recommended, for file size verification)
• storage.multipartUploads.create (optional but recommended, for large file uploads)

3. Generate HMAC keys

LangSmith connects to GCS using the S3-compatible XML API, which requires HMAC keys rather than a service account JSON key.

Generate HMAC keys for your service account:

gcloud storage hmac create \
  langsmith-bulk-export@YOUR_PROJECT.iam.gserviceaccount.com

Save the accessId and secret from the output. You can also generate HMAC keys in the GCP Console under Cloud Storage → Settings → Interoperability → Create a key for a service account.

4. Create a bulk export destination

Create a destination in LangSmith pointing to your GCS bucket. Set endpoint_url to https://storage.googleapis.com to use the GCS S3-compatible API.

You will need your LangSmith API key and workspace ID.

curl --request POST \
  --url 'https://api.smith.langchain.com/api/v1/bulk-exports/destinations' \
  --header 'Content-Type: application/json' \
  --header 'X-API-Key: YOUR_API_KEY' \
  --header 'X-Tenant-Id: YOUR_WORKSPACE_ID' \
  --data '{
    "destination_type": "s3",
    "display_name": "GCS for BigQuery",
    "config": {
      "bucket_name": "YOUR_BUCKET_NAME",
      "prefix": "YOUR_PREFIX",
      "endpoint_url": "https://storage.googleapis.com"
    },
    "credentials": {
      "access_key_id": "YOUR_HMAC_ACCESS_ID",
      "secret_access_key": "YOUR_HMAC_SECRET"
    }
  }'

prefix is a path within the bucket where LangSmith will write exported files. For example, langsmith-exports or data/traces. Choose any value that works for your bucket layout.

LangSmith validates the credentials by performing a test write before saving the destination. If the request returns a 400 error, refer to Debug destination errors.

Save the id from the response; you will need it in the next step.

Temporary validation file

During destination creation (and credential rotation), LangSmith writes a temporary .txt file to YOUR_PREFIX/tmp/ to verify write access, then attempts to delete it. The deletion is best-effort: if the service account lacks storage.objects.delete, the file is not deleted and the tmp/ folder remains in your bucket.

The tmp/ folder does not affect exports, but it will be included in broad GCS URI globs (e.g., gs://YOUR_BUCKET_NAME/YOUR_PREFIX/*).

5. Create a bulk export job

Create an export targeting a specific project. Use format_version: v2_beta for BigQuery compatibility—it produces UTC timezone-aware timestamps that BigQuery handles correctly.

You will need the project ID (session_id), which you can copy from the project view in the Tracing Projects list.

One-time export:

curl --request POST \
  --url 'https://api.smith.langchain.com/api/v1/bulk-exports' \
  --header 'Content-Type: application/json' \
  --header 'X-API-Key: YOUR_API_KEY' \
  --header 'X-Tenant-Id: YOUR_WORKSPACE_ID' \
  --data '{
    "bulk_export_destination_id": "YOUR_DESTINATION_ID",
    "session_id": "YOUR_PROJECT_ID",
    "start_time": "2024-01-01T00:00:00Z",
    "end_time": "2024-02-01T00:00:00Z",
    "format_version": "v2_beta",
    "compression": "snappy"
  }'

Scheduled (recurring) export:

curl --request POST \
  --url 'https://api.smith.langchain.com/api/v1/bulk-exports' \
  --header 'Content-Type: application/json' \
  --header 'X-API-Key: YOUR_API_KEY' \
  --header 'X-Tenant-Id: YOUR_WORKSPACE_ID' \
  --data '{
    "bulk_export_destination_id": "YOUR_DESTINATION_ID",
    "session_id": "YOUR_PROJECT_ID",
    "start_time": "2024-01-01T00:00:00Z",
    "interval_hours": 24,
    "format_version": "v2_beta",
    "compression": "snappy"
  }'

Snappy compression is fast and widely supported by BigQuery. For all available options, refer to Bulk export trace data, including field filtering and filter expressions.

Output file structure

Exported files land in GCS using a Hive-partitioned path structure:

gs://YOUR_BUCKET_NAME/YOUR_PREFIX/export_id=<uuid>/tenant_id=<uuid>/session_id=<uuid>/resource=runs/year=<year>/month=<month>/day=<day>/<filename>.parquet

The partition columns in the path (export_id, tenant_id, session_id, resource, year, month, day) are available as queryable columns in BigQuery when Hive partition detection is enabled.

6. Load data into BigQuery

BigQuery offers two ways to access your exported data. Both require granting the BigQuery service account read access to your GCS bucket first. Choose based on your needs:

• External table: data stays in GCS and BigQuery queries it in place. No storage costs in BigQuery, but query performance is slower than native storage. Refer to Required roles.
• Native table: data is copied into BigQuery storage. Faster queries and full support for BigQuery features, but incurs BigQuery storage costs. Refer to Required permissions.

Create the table

External table

An external table queries data directly from GCS without copying it into BigQuery.

1. In the BigQuery console, expand your project and dataset in the Explorer pane.
2. Click the dataset’s Actions menu (three dots) and select Create table.
3. Under Source:
   • Set Create table from to Google Cloud Storage.
   • Set the file path to gs://YOUR_BUCKET_NAME/YOUR_PREFIX/export_id=*. Using export_id=* scopes BigQuery to Hive-partitioned export directories and excludes the tmp/ folder that LangSmith writes during destination validation (see Temporary validation file).
   • Set File format to Parquet.
4. Check Source data partitioning, then:
   • Set Source URI prefix to gs://YOUR_BUCKET_NAME/YOUR_PREFIX.
   • Set Partition inference mode to Automatically infer types.
5. Under Destination:
   • Select your project and dataset.
   • Enter a table name, for example langsmith_runs.
   • Set Table type to External table.
6. Under Schema, enable Auto-detect.
7. Click Create table.

The partition path columns (export_id, tenant_id, session_id, resource, year, month, day) are available as queryable columns. Filter on year, month, or day in your queries to enable partition pruning.

Native table

A native table transfers the Parquet data into BigQuery storage for full query performance.

1. Go to the Data Transfer page in the Google Cloud console and select + Create transfer.

2. For Source type, select Google Cloud Storage.

3. Enter a Transfer name. You’ll have access to edit the transfer at a point if necessary.

4. Select a Schedule option. If you do not want to repeat the export, you can select On demand and trigger the export manually.

5. In the BigQuery console, expand your project and dataset in the Explorer pane.

6. Click the dataset’s Actions menu (three dots) and select Create table.

7. Under Source:

   • Set Create table from to Google Cloud Storage.
   • Set the file path to gs://YOUR_BUCKET_NAME/YOUR_PREFIX/export_id=*. Using export_id=* excludes the tmp/ folder that LangSmith writes during destination validation (see Temporary validation file).
   • Set File format to Parquet.

8. Check Source data partitioning, then:

   • Set Source URI prefix to gs://YOUR_BUCKET_NAME/YOUR_PREFIX.
   • Set Partition inference mode to Automatically infer types.

9. Under Destination:

   • Select your project and dataset.
   • Enter a table name, for example langsmith_runs.
   • Set Table type to Native table.

10. Under Advanced options, set Write preference to Write if empty for a new table.

11. Click Create table.

BigQuery runs a load job to copy the data. The Hive partition columns appear as regular columns in the table. For the full list of available data columns, see Exportable fields.

Credential rotation

To rotate your HMAC keys without interrupting active exports:

1. Generate new HMAC keys in GCP for the same service account.

2. Call the PATCH endpoint with the new credentials:

   curl --request PATCH \
     --url 'https://api.smith.langchain.com/api/v1/bulk-exports/destinations/YOUR_DESTINATION_ID' \
     --header 'Content-Type: application/json' \
     --header 'X-API-Key: YOUR_API_KEY' \
     --header 'X-Tenant-Id: YOUR_WORKSPACE_ID' \
     --data '{
       "credentials": {
         "access_key_id": "NEW_HMAC_ACCESS_ID",
         "secret_access_key": "NEW_HMAC_SECRET"
       }
     }'


   LangSmith validates the new credentials with a test write before saving. A new tmp/ file may appear in your bucket during this validation (see Temporary validation file).

3. Keep old HMAC keys active until all in-flight export runs complete. Both credential sets are valid simultaneously during the transition window.

4. Delete the old HMAC keys in GCP once you have confirmed no in-flight runs are using them.

For full details, see Rotate destination credentials.

Troubleshooting

Symptom	Likely cause	Fix
400 Access denied on destination creation	HMAC credentials lack write permission	Verify the service account has storage.objects.create on the bucket
400 Key ID you provided does not exist	HMAC access ID is invalid	Regenerate HMAC keys in GCP
400 Invalid endpoint	Endpoint URL is malformed	Use exactly https://storage.googleapis.com
BigQuery table shows no rows	Export not yet complete	Check export status with GET /api/v1/bulk-exports/{export_id}
BigQuery partition pruning not working	Incorrect source URI prefix	Ensure the source URI prefix ends before the first partition key, e.g. gs://BUCKET/PREFIX
BigQuery picks up tmp/ files	Broad file path glob	Use export_id=* in your file path instead of *

For additional error codes and export status details, see Monitor and troubleshoot bulk exports.

---
